| TECHNICAL FEATURES | STANDARD VERSION | ANTI-MOISTURE VERSION |
|---|
| Pt100 | Ni120 | NTC (R) | Pt100 | Ni120 |
| Available diameters | 8, 13, 16 and 20 mm | 8 mm | 8 mm |
| Available lengths (enquire) | From 0.6 to 14 m | From 0.6 to 8 m | From 0.6 to 7.2 m |
| Max. operating temperature | Up to 230ºC |
| Temperature sensors | RTD Pt100 or Ni120, NTC (R) (thermocouple J, enquire) |
| Max. operating pressure | 120 (Ø8) / 100 (Ø13) / 70 (Ø16) / 65 (Ø20) bar at 200ºC |
| Max. curvature radius | 200 (Ø8) / 300 (Ø13) / 350 (Ø16) / 400 (Ø20) mm |
| Hydraulic connection | Female nut JIC 9/16′ (Ø8) 3/4′ (Ø13), 1 1/16′ (Ø16) M30x1.5 (Ø20) | Female nut M16x1.5 | Female nut JIC 9/16′ (Ø8) 3/4′ (Ø13), 1 1/16′ (Ø16) M30x1.5 (Ø20) |
| Electrical power supply | 200 or 230 V AC (control from the melting unit) |
